7 Function 12.1 Inch Patient Monitor CMS 8000

Description

Specifications

The Monitor Has Abundant Functions That Can Be Used For Clinical Monitoring With Adult, Pediatric And Neonate.
Users May Select Different Parameter Configuration According To Different Requirements. The Monitor, Power Supplied By 100-240V～,50/60Hz, Adopts 12.1” Color TFT LCD Displaying Real-Time Date And Waveform.
It Can Synchronously Display Eight-Channel Waveform And Full Monitoring Parameters Equipped With An Optional 48mm Thermal Recorder.
The Monitor Can Be Connected To The Central Monitoring System Via Wire Or Wireless Network To Form A Network Monitoring System.

Functions
Standard Parameters: ECG, RESP, SpO2, PR, NIBP, Dual-Channel TEMP
1)ECG   Heart Rate(HR)
ECG Waveform
Arrhythmia And ST-Segment Analysis
2)RESP   Respiration Rate(RR)
Respiration Waveform
3)SpO2   Oxygen Saturation(SpO2)
Pleth Ys Mogram (PLETH) Waveform
Pulse Rate(PR)
Bar Graph
4)NIBP   Systolic Pressure(SYS), Diastolic Pressure(DIA), Mean Pressure(MEAN)
5)TEMP   T1, T2, TD
6)IBP(Optional) CH1：SYS，DIA，MAP
CH2：SYS，DIA，MAP
IBP Waveform
7)CO2 EtCO2
InsCO2:Inspired Minimum CO2
AwRR: Air Way Respiration
It Has Abundant Functions, Such As Audible And Visual Alarm, Trend Data Storage And Output, NIBP Measurement, Alarm Event Marking And Drug Concentration Calculation, Etc.

Features

12.1” TFT Color LCD, Multi-Language Interface(Simplified Chinese, Traditional Chinese, English, French, German, Turkish, Spanish, Portuguese, Italian, Dutch, Romanian, Russian, Kazakh, Polish, Czech).
Fan Less Design, Quiet, Energy-Saving And Clean, Which Reduces The Possibility Of Cross-Infection.
All-Round Monitor For Adult, Pediatric And Neonate.
With Standard Interface, Oxygen Graph, Trend Graph, Big Character Interface And View Bed, Convenient To Observe.
Finish All Operations By Keys And Knobs.
Maximum 8-Channel Waveform Synchronous Display.
Display 7-Lead ECG Waveform On One Screen, Cascade ECG Waveform Display
Adopt Digital SpO2 Technology, Anti-Motion And Anti-Ambient Light Interference, And Measurement Can Be Performed Under The Circumstance Of Weak Filling.
Heart Rate Variability (HRV) Analysis Function
NIBP Measurement Mode: Manual/AUTO/STAT, Storage For 4800-Group NIBP Data.
Review For 71 Alarm Events Of All Parameters And 60 Arrhythmia Alarm Events.
Drug Concentration Calculation And Titration Table Functions.
One-Touch Printing Of Trend Graph
Connect To Central Monitoring System By 3G, Wi-Fi Or Wired Mode.
AC/DC, Built-In Rechargeable Lithium Battery Achieve Uninterrupted Monitoring.
Anti-High Frequency Surgical Unit, Defibrillation-Proof (Special Leads Are Necessary).

Data Saving Up To 72 Hours In The Internal Memory
Up To 150 Minutes Use With A Battery Removable And Rechargeable

Performance
▲ECG

Lead Mode	3-Lead Or 5-Lead
Lead Selection	I, II, III, AVR, AVL, AVF, V
Waveform	5-Lead, Dual-Channel
Gain	2.5mm/MV, 5.0mm/MV, 10mm/MV, 20mm/MV, 40mm/MV
Scan Speed	12.5mm/S, 25 Mm/S, 50 Mm/S
HR	Measurement And Alarm Range: 15～350 Bpm
Accuracy	±1 % Or ±1 Bpm, Whichever Is Greater
Alarm Accuracy	± 2 Bpm
Resolution	1 Bpm
ST-Segment Monitoring	Measurement And Alarm Range: -2.0 MV ～ +2.0 MV
Accuracy	-0.8 MV～+0.8 MV ±0.04 MV Or ±10%, Whichever Is Greater
Other Range	Unspecified
Arrhythmia Analysis	ASYSTOLE, VFIB/VTAC, COUPLET, BIGEMINY, TRIGEMINY, R ON T, VT>2, PVC, TACHY, BRADY, MISSED BEATS, PNP, PNC
Pacemaker	Yes

▲RESP

Method	R-F(RA-LL) Impedance
Respiration Rate	Measurement And Alarm Range: 0～150 Rpm
Resolution	1 Rpm
Measurement Accuracy	±2 Rpm
Alarm Accuracy	±3 Rpm
Apnea Alarm	10～40s
Scan Speed	6.25 Mm/S, 12.5 Mm/S, 25 Mm/S

▲NIBP

Method	Oscillometer
Mode	Manual/AUTO/STAT
Measurement Interval In AUTO Mode	1/2/3/4/5/10/15/30/60/90/120/240/480/960 Minutes
Measurement Period In STAT Mode	5 Minutes
Measurement And Alarm Range	10 ～ 270 MmHg
Resolution	1 MmHg
Cuff Pressure Accuracy	±3 MmHg
Measurement Accuracy	Maximal Mean Deviation: ±5 MmHg
Aximal Standard Deviation	8 MmHg
Over-Pressure Protection	Adult Mode: 297±3 MmHg Pediatric Mode: 240±3 MmHg Neonatal Mode: 147±3 MmHg

▲SpO2

Measurement And Alarm Range	0 ～ 100%
Resolution	1%
Measurement Accuracy	70%～100%: ±2%
Unspecified	0%～69%

▲PR

Measurement And Alarm Range	30 ～ 250 Bpm
Measurement Accuracy	±2 Bpm Or ±2%, Whichever Is Greater

▲TEMP

Channel	Dual-Channel
Measurement And Alarm Range	0 ～ 50℃
Resolution	0.1 ℃
Accuracy	±0.1 ℃

▲EtCO2

Method	Side Stream Or Mainstream
Measuring Range	0～150mmHg
Resolution	0～69 MmHg, 0.1 MmHg 70～150 MmHg, 0.25 MmHg
Accuracy	0～40 Mm Hg ±2 Mm Hg 41～70 Mm Hg ±5% 71～100 Mm Hg ±8% 101～150 Mm Hg ±10%
AwRR Range	2～150 Rpm
AwRR Accuracy	±1BPM
Apnea Alarm	Yes

Accessories
1)Adult Fingertip SpO2 Probe (5-Pin)
2)Adult NIBP Cuff
3)NIBP Extension Tube
4)ECG Lead Cable
5)ECG Electrode
6)Temperature Probe
7)Power Cord
8)User Manual

Physical Characteristic

Dimension	314 Mm(L) × 145 Mm(W) × 264 Mm(H)
Weight	3.9 Kg

Additional information

Warranty Period	2 year
Brand	CONTEC
